Highway guardrails are safety devices manufactured from high strength steel sheets to the typical "W" profile and mounted on "C" Channel post spaced at either two (2) or four (4) meters apart. Such highway safety barriers are installed at edges of roads and highway to prevent vehicles veering off the roads and highways, in median to separate traffic flow, at roundabouts and many parts of a modern highway or expressway. The highway guardrails in Malaysia are manufactured complying to AASHTO M180-89 Standards. The manufacturing process can either employ roll formers or hydraulic press machine to form the corrugated "W" beam steel Highway guardrails and the "C" Channel post.
Highway Guardrail Manufacturing Company in Malaysia
Copyright @ 2013 Galvaco Industries Sdn. Bhd. All Rights Reserved
The "W" Beams guardrails
"C" Channel Post & Packers
GALVACO INDUSTRIES SDN BHD (99584-X)
Address: No.16, Jalan Sabak Bernam, Hicom Industrial Estate (Section 26), 40000 Shah Alam, Selangor Darul Eshan,
Tel: 603-5191 4216, Fax: 603-5191 4217
The highway guardrail manufacturing plant also produces various types of steel channel support post, steel channel blocks, various types of highway guardrail end sections, highway guardrail terminal sections, guardrail reflectors and other related guardrail accessories. These highway guardrails and other highway safety crash barriers are hot dip galvanized to international standards such as BS EN ISO 1461 or ASTM A123 for corrosion protection and to ensure durability in all weather application. Hot dip galvanizing is the proven and worldwide accepted corrosion protection process for iron and steel products.
High Strength Steel from the Uncoiler
The leveling machine flattens the steel from the uncoiler
Cutting to length and Holes perforation
The steel sheets are then fed into the roll formers to produce the "W" profile highway guardrail beams
HIGHWAY GUARDRAILS OF MALAYSIA
High Strength Steel coils
GUARDRAILCO HIGHWAY GUARDRAIL MANUFACTURING PLANT
The highway guardrail manufacturing process employs roll formers for continuous production of guardrail "W" beams. It starts with the uncoiling of high strength steel in coil form through the leveling machine. The flattened steel sheets are then cut into suitable lengths, punched with the necessary holes for splice bolts before being fed into the roll former machine to produce the "W" profile highway guardrail beams.
GUARDRAILCO HIGHWAY GUARDRAIL MANUFACTURING PROCESS
